Safe Low Voltage Battery Powered Rail Transfer Cart for Transportation
Product Preview of Low Voltage Transfer Cart
BDG series rail powered transfer car get its power from railway. The 380V alternating-current is transformed into safe current 36V. The current collectors mounted on the trolley get the 36V current from Combined with PLC system, full automatic operation is available. It’s widely used, life long, safe and flexible.
Parameter of Low Voltage Transfer Cart
| Model | BDG-2t | BDG-16t | BDG-30t | BDG-50t | BDG-100t | BDG-150 |
| Rated Load(t) | 2 | 16 | 30 | 50 | 100 | 150 |
| Table Size (mm) | Length(L) | 2000 | 4000 | 4500 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2200 | 2500 | 2800 | 3000 |
| Height(H) | 450 | 500 | 600 | 650 | 850 | 1200 |
| Wheel Base(mm) | 1200 | 2800 | 3200 | 4200 | 4900 | 7000 |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 2000 | 2000 |
| Wheel Diameter (mm) | 270 | 350 | 400 | 500 | 600 | 600 |
| Running Speed (m/min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 |
| Running Distance (m) | 70 | 70 | 70 | 50 | 50 | 50 |
| Motor Power(kw) | 1 | 2 | 3.5 | 5.5 | 11 | 15 |
| Transformer Power (KVA) | 3 | 6.8 | 10 | 10 | 30 | 30 |
| Transformer Quantity | 1 | 1 | 1 | 1 | 1 | 1 |
| Running Distance (m) | 70 | 70 | 70 | 50 | 50 | 50 |
| Recommended Rail Model | P15 | P24 | P43 | P43 | QU100 | QU100 |
Customer visit
Currently, our coil transfer carts not only have been sold in China, but also exported to American, Germany, Thailand, Holland, Turkey South Africa, Nepal, etc. We are becoming more and more popular around the world and get high evaluations from our cooperators.
Package & Transportation
The body of the cart is packed with tarp, the small parts will be packed with wooden cases. According the table size and quantity, the cart would be carefully fixed and transported by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.
After sales service
We have full confidence and high responsibilities in our products. With quick quality information feedback system and technology service team, we can provide with high quality service for you. Our guarantee period is 2 years, after making sure the product is working well. During this period, we can repair, change the machine for you freely. After this period, we only charge cost price for you.
Contact Information
Help you to choose the most suitable cart
Thank you very much for looking through the information above. If you are interested in our products, please send us an E-mail and tell us the following information. Thank you!
- What material/cargo are you going to transfer?
- What load capacity do you want?
- What kind of ground does the transfer cart operate on? (rails or cement floor)
- What’s the specification table size ? (length,width and height)
- How long is the running distance?
- How many working hours do you have everyday?
